Discussion Starter · #1 · (Edited)
Bought the car in October 09, loved it. 1998 T-Red GTI w/ DE leftovers. CEL came on the second I rolled out of the used dealer I bought it from, knew I was in for it :rolleyes: This is a glimpse from the two years ago, to today with my car, so if you don't want to read, look at the pics.

The day I brought it home:



Strong VR, no mechanical issues, just needed an ignition switch and 02 sensors and was good to go. Deleted res on the exhaust gave it a great sound. At the time HS and barely a part-time job didn't give me much 'play money', but I managed the little things over time like smoked side markers and eventually smoked ecodes.

Center dummies fell off :mad:


Went through 2 Jersey winters so far, and the winter won. Rust got beyond bad, and got to the point of where it wasn't structurally safe anymore.


This was after hitting a nice pothole caused by the weak pavement after the snowstorm: :banghead:


Car sat for a week or so until I could drop the extra cash on a replacement panel and then labor (don't want to talk about the price) But I was far too attached to the car at this point.

All done:


Threw in my Jahre belts:



THEN the transmission went, could have avoided it, but my cheap ass didn't want to buy the bit to check the trans fluid, lesson learned :( But I got a used trans w/ a bonus B&M short shifter for a good deal and with the help of vortex got it all swapped and buttoned up, even got the billet shifter bushings while I was at it (SO WORTH IT).



Fogs filled with water, so this was a cheap fix to my lack of fog lights, and pretty much how the car sits today.


Now I'm hooked. Loved working on it before, but now I want more. Made the car last for another winter while I hoarded parts to rebuild the motor, along with coilovers and some go fast goodies. Also threw on some Passat bottlecaps and Inpro smoked tails. No point in installing suspension or go-fast stuff since that rust I was talking about? Got worse.





Floor is completely fked, holes everywhere and bending down on the driver side, pass side needed love too. Fenders / fender wells had holes, both rockers went bent to hell (covered by sideskirts) and rusted, hatch was rusted behind plate tub, and the gas cap started bubbling up.






:mad::what::facepalm::(

THEN I found a DIY thread for the rockers, which is how I got in contact with Bob (silentdub on here) and when I can't say enough about what this guy can do with bodywork. Truly phenomenal. Awesome guy and he did an excellent job on EVERYTHING. The pics speak for themselves.











So then I got it back home, ready to swap the motor from my recently purchased 96 GTI (brother's old car, he bought a 2011 GTI so I took his mk3 off his hands, lots of motor work done).

I figure instead of taking the time to rebuild my VR, why not take one that has already been rebuilt a few months ago and swap it into the red one? Makes sense to me, so I proceed.





Crane, meet motor:


Out:



That's as far as I got for now, I'll be working on it more tomorrow so I'll keep this thread updated. Plans for this season is to give it a nice T-Red respray and get the new motor running perfect. Next season is boost. My other GTI is in the background in the last pic, You'll see me at WF:thumbup:

:wave:


·
Registered
Joined
·
5,480 Posts
I'm glad you are happy with my bodywork. That hood had more waves than a god damn ocean. I think we got them all though.


Anyone with an MKIII with rotted rocker panels, the rockers are not the only thing rotted! The floor and other mount points are rotted too.

This car took a lot of bodywork. The two lower fenders were rotted, wheel wells had hole, wheel well lip was blasted, gas cap area was lasted.

New rear floor pans, structural support was replaced as well.

While I was working on that and waiting for stuff to dry, we went ahead and fixed all of the dings on this car. The sides look like someone played morse code down each body line.

The roof was in perfect condition and required 0 work though. :thumbup:


·
Registered
Joined
·
2,587 Posts
Anyone with an MKIII with rotted rocker panels, the rockers are not the only thing rotted! The floor and other mount points are rotted too.
How do you normally go about replacing rockers? Floors are pretty straight forward, but do you source new rockers or search for a donor car?


·
Registered
Joined
·
4,629 Posts
Discussion Starter · #8 ·
hey i thought i was the only one with a SMASHED rocker :thumbup:
USED to have a smashed rocker, USED to :laugh:

I'm glad you are happy with my bodywork. That hood had more waves than a god damn ocean. I think we got them all though.

Anyone with an MKIII with rotted rocker panels, the rockers are not the only thing rotted! The floor and other mount points are rotted too.

This car took a lot of bodywork. The two lower fenders were rotted, wheel wells had hole, wheel well lip was blasted, gas cap area was lasted.

New rear floor pans, structural support was replaced as well.

While I was working on that and waiting for stuff to dry, we went ahead and fixed all of the dings on this car. The sides look like someone played morse code down each body line.

The roof was in perfect condition and required 0 work though. :thumbup:
Can't say it enough. Phenomenal work = understatement.

:thumbup: And a :beer: to you for helping out in my trans thread last season.

ECS sells replacement rocker panels. Check it out.

http://www.ecstuning.com/Volkswagen-Golf_III--VR6_12v/Search/Rocker/ES2180509/

They also sell replacement wheel arches.
ECS didn't have them ready to be shipped when I bought mine, I got them from shermanparts for like $66 per side + shipping. It's the same brand so getting them from ECS now is a STEAL for them. Fit perfectly.

Didn't get much done today, because I decided to go to the beach instead. Managed to get the front crossmember down to check the frame rails for rust. There's some, but it's not too bad.


·
Registered
Joined
·
4,629 Posts
Discussion Starter · #10 ·
Some progress. No more AC! Anyone know if I can leave the piece by the firewall open like that?




You can see the rust on frame rails, so I took it down to bare metal and hit it with rust inhibitor.




Had to get the underside of the rails also.


·
Registered
Joined
·
5,480 Posts
How do you normally go about replacing rockers? Floors are pretty straight forward, but do you source new rockers or search for a donor car?
Nah, klokerholk makes replacement rockers, hell they make all the replacement parts for dubs. They are located in Holland or some country like that.


The problem is, when the rockers are shot, the metal behind them is usually screwed up too. The rocker panel is just cosmetic, nothing structural about it, the steel behind it is a structure piece and you need to ensure it is good.


·
Registered
Joined
·
908 Posts
Nah, klokerholk makes replacement rockers, hell they make all the replacement parts for dubs. They are located in Holland or some country like that.


The problem is, when the rockers are shot, the metal behind them is usually screwed up too. The rocker panel is just cosmetic, nothing structural about it, the steel behind it is a structure piece and you need to ensure it is good.
yah, i dont think its all that messed up but what do i know without cutting into it. anyways just look at afazz build thread


·
Registered
Joined
·
5,480 Posts
this is super inspirational. :thumbup:
Good work, Evan.
and Bob, silentdub, will certainly be calling on you for body work stuff when my build starts, if ever. :banghead:
Yeah, I'm game. If anyone needs some work done, I'm in Newark De.

I work out of my house, this is a side thing. I just need whoever to plan accordingly since I only have so much space. I just got a Pontiac G5 in that hit a deer, so this is what I am working on now while rebuilding a 1.6 Diesel.

here's a link to my 1st MK3 Rocker Job. http://www.mk1dubz.com/forums/showthread.php?t=642


That car took me 3 months. New Rockers, Floors, Dent/Ding removal, Shaved door handles, Shaved rear hatch, Shaved license plate area, gas filler, Shaved the side bodyline as well as the gutters on the roof, all perfectly smooth.

Oh, we also modified the hood.



The hood follows the contour of the car and covers the headlights. This took a little bit to get it right. There were two bends in it, so it took some time.

Don't even ask me how much, because you probably couldn't afford it, that entire car was a major project.


Oh, forgot to mention I also had to replace the rear QTR panel as well as the inner wheel well.


·
Registered
Joined
·
4,629 Posts
Discussion Starter · #17 ·
this is super inspirational. :thumbup:
Good work, Evan.
and Bob, silentdub, will certainly be calling on you for body work stuff when my build starts, if ever. :banghead:
Thanks PK, you need to get back on to your own GTI :thumbup::D

And Bob, that hood came out cool, I wanna see that one when it's all done.

Today I finished up all the rust on frame rails, primed and good to go. I went to take out the downpipe / exhaust and it seems my only options are cutting my exhaust and re-welding or dropping the rear beam.

Wish I could just pull the fker out


·
Registered
Joined
·
5,480 Posts
Actually Evan, the hood is done, it was actually sitting up against the wall when you were here. I should have pointed it out to you.

hell it would have been easier to just swap hoods with ya! Your hood had more waves than the ocean.


·
Registered
Joined
·
4,629 Posts
Discussion Starter · #19 ·
Actually Evan, the hood is done, it was actually sitting up against the wall when you were here. I should have pointed it out to you.

hell it would have been easier to just swap hoods with ya! Your hood had more waves than the ocean.
Really? I'll check it out next time (if it's still there). I wish I jumped on the $40 OEM hoods when they were still available, prob woulda saved you a ton of work. Looks just as good now though!

Replaced my steering rack boots when I did the R32 / poly control arm bushings, but the passenger side boot is all ****ed up again. So I ordered another boot and got some poly sway bar bushings while I was at it. Found out that I didn't have swaybar bushings at all :facepalm: That explains some really dumb noises.

Also decided to keep my current exhaust / dp on there. It's gonna be changed when I boost it next season so I'm not going through the hassle now.

Now I have to start unboxing everything I have hoarded over the winter. :D
